Educational TCD GC System
32
  • TCD Detector with User Replaceable Filaments
  • Carrier Gas Electronic Pressure Control (EPC)
  • 1 channel PeakSimple Data System
  • 1-meter Silica Gel Column
  • On-Column Injector
    ...on the ultra compact 310 chassis

The Educational TCD GC system is ideal for undergraduate chemistry classes with labs. Configured on the ultra compact 310 chassis, the Educational GC includes a traditional 4-filament Themal Conductivity Detector that can heat to 275oC. The built-in single channel PeakSimple data system provides easy and powerful data aquisition, as well as temperature programming for the column oven. The column oven is programmable to 400oC with unlimited ramps and holds, and is equipped with fast cool-down fans. Electronic Pressure Control (EPC) for the carrier gas provides rock-solid retention time reproducibility.
Because of their low cost and upgrade-ability* with other SRI detectors and injectors, these GCs are also used by thrifty labs for simple applications such as landfill gas analysis, stack monitoring, and quality control.
0310-1000
Educational TCD GC System
£4,544.00
(VOLTAGE: for 110VAC, use 0310-1000-1; for 220VAC, use 0310-1000-2)
*NOTE: Because of batch manufacturing efficiencies, educational models are less expensive than equivalent GC's manufactured to order. No customization of educational models is available prior to initial sale, although normal factory retrofit services are available after delivery.
